-45-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
9 Temp C-A Warning(Normal)
Temp. C-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100 100 0-100
10 Temp A Warning (Eco)
Temp. A to judge the Temp Error at
Eco (Room)
44 44 43 44 30-100
11 Temp B Warning (Eco)
Temp. B to judge the Temp Error at
Eco(Panel)
60 60 60 60 30-100
12 Temp C Warning (Eco)
Temp. C to judge the Temp Error at
Eco(Panel)
60 60 63 63 30-100
13 Temp B-A Warning (Eco)
Temp. B-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100 100 0-100
14 Temp C-A Warning (Eco)
Temp. C-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100 100 0-100
15
Temp A Warning Offset
(Temp)
Offset of Temp Error (Temp.)
Error Setting Value is increased XC at
the below condition
* Standby
* Right to turn on the lamp
*Right to change the Lamp mode
5 0-100
16
Temp B Warning Offset
(Temp)
5 0-100
17
Temp C Warning Offset
(Temp)
5 0-100
18
Temp B-A Warning Offset
(Temp)
0 0-100
19
Temp C-A Warning Offset
(Temp)
0 0-100
20
Temp A Warning Offset
(Time)
Offset of Temp Error (Minutes)
Error Setting Value is increased X min-
ute at the below condition
* Standby
* Right to turn on the lamp
*Right to change the Lamp mode
3 0-100
21
Temp B Warning Offset
(Time)
3 0-100
22
Temp C Warning Offset
(Time)
3 0-100
23
Temp B-A Warning Offset
(Time)
3 0-100
24
Temp C-A Warning Offset
(Time)
3 0-100
Group
254
Fan Control Range Setting (Temp./Voltage)
Normal Ceiling
HiLand-
Normal
HiLand-
Ceiling
10 Normal Fan Control Min Temp
Temp Senser Control Start/End Tem.p
at Normal
33 33 35 35 20-100
11
Normal Fan Control Max
Temp
38 39 39 39 20-100
12 Normal Fan1 Min
Fan voltage value at Normal (unit:
0.1V)
72 77 95 95 0-255
13 Normal Fan1 Max 125 125 125 125 0-255
14 Normal Fan2 Min 68 75 85 90 0-255
15 Normal Fan2 Max 80 80 80 80 0-255
16 Normal Fan3 Min 77 82 95 95 0-255
17 Normal Fan3 Max 135 135 135 135 0-255
20 Eco Fan Control Min Temp
Temp Senser Control Start/End Tem.p
at Eco
30 30 35 35 20-100
21 Eco Fan Control Max Temp 38 38 39 39 20-100
22 Eco Fan1 Min
Fan voltage value at Eco (unit: 0.1V)
50 55 85 85 0-255
23 Eco Fan1 Max 115 120 125 125 0-255
24 Eco Fan2 Min 45 45 60 60 0-255
25 Eco Fan2 Max 50 50 62 62 0-255
26 Eco Fan3 Min 70 75 90 95 0-255
27 Eco Fan3 Max 125 125 125 125 0-255
Group
255
Fan Start/Cooling Setting
0 Fan1 Initial Volt
Fan Start Voltage (0.1V)
55 0-255
1 Fan2 Initial Volt 55 0-255
2 Fan3 Initial Volt 55 0-255
4 Fan1 Cooling Speed Fan Voltage at Power Off (0.1V) 130 0-255
5 Fan2 Cooling Speed 130 0-255
6 Fan3 Cooling Spees 130 0-255
8 Cooling Time L1
Cooling Time stting at Fan Mode L1 (x
30 sec)
1: 30, 3: 90, 15: 450 sec.
2 1-15
9 Cooling Time L2
Cooling Time stting at Fan Mode L2 (x
30 sec)
1: 30, 3: 90, 15: 450 sec.
3 1-15
10 Temp Error Cooling Time
Cooling Time setting at Temp Erro (x
30 sec)
3 1-15
11
OnStart Cooling Start Thresh-
old
38 0-100
12 After shutdown cooling Cooling after shutdown (0: No, 1: Yes) 1 0-1
Group
256
Fan Lamp Voltage Down Setting
0 Lamp Voltage
Current Lamp Voltage (0.1V)(Read
only)
- 0-255
