Sanyo PLC-XU300A Service Manual

-46-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
1 Lamp Vol Threshold
Threshold to judge Lamp Voltage
Down ( V×10)
0 30-90
2 Fan1 Speed Gain
Additional Fan Speed of Min at Lamp
Voltage Down (unit: 0.1V)
10 0-255
3 Fan2 Speed Gain 10 0-255
4 Fan3 Speed Gain 10 0-255
Group
257
Fan Dimmer Setting
0
Dimmer Average Chech
Period
Dimmer Average measurement Time
(0:10sec. 1:30sec. 2:60 sec. 90:
sec...10:30sec.)
1 0-10
1 Dimmer Average Dimmer Average Value (Read only) -
2 Last Voltage Difference -
3 Voltage Difference Goal -
Group
258
FAN network mode IC Temp.
0
Standby Cooling Check
Cycle
Standby Cooling Check Cycle 5 -
1
Standy Cooling Start
Threshold
Standy Cooling Start
Threshold
40 -
2 Standby Cooling Enable Standby Cooling Enable 1 -
Group
260
Auto Calibration(Common)*Auto Calibration
0 Execute Calibration 0 0 - 1
Executes Auto-Calibration when
changiing the Value (PC White
100%)
1 Loop Count
Maximum Execution Times (OFFSET-
>GAIN)
10 1 - 30
2 Auto Status
Result of Auto-Calibration (Last
Memory)
0 0 / 1 / 9
0: OK, 1: Adjusting,9: Error *
ReadOnly
3 AutoWait Wait Value for each setting 1 1 - 20
4 CHECK -Tolelance Torelance of OFFSET 2 1 - 255
Group
261
Auto Calibration (RGB)
0 OFFSET AREA H START
Black Level Acquiring Area H-Start
Position
975 0 - 1000
1 OFFSET AREA V START
Black Level Acquiring Area V-Start
Position
500 0 - 1000
2 GAIN AREA H START
White Level Acquiring Area H-Start
Position
25 0 - 1000
3 GAIN AREA V START
White Level Acquiring Area V-Start
Position
500 0 - 1000
4 Image AREA H WIDTH Black/White Level Acquiring Area 13 0 - 4095
5 Image AREA V HIGHT
Black/White Level Acquiring Area
Height
9 0 - 4095
6 OFFSET target Target Value of Black Level Adj. 3 0 - 127
7 OFFSET torelance Torelance of Black Level Adj. 1 1 - 127
8 GAIN target Target Value of White Level Adj. 238 0 - 255
9 GAIN torelance Torelance of White Level Adj. 1 1 - 255
Group
262
Auto Calibration (CVBS/SVIDEO)
0 Y Image Area Start X Y Acquiring Area H-Start Position 20 0 - 1000
1 Y Image Area Start Y Y Acquiring Area V-Start Position 200 0 - 1000
2 Cb Imange Area Start X Cb Acquiring Area H-Start Position 500 0 - 1000
3 Cb Imange Area Start Y Cb Acquiring Area V-Start Position 200 0 - 1000
4 Cr Imange Area Start X Cr Acquiring Area H-Start Position 500 0 - 1000
5 Cr Imange Area Start Y Cr Acquiring Area V-Start Position 200 0 - 1000
6 Image Area H Width Image Level Acquiring Area 8 0 - 4095
7 Image Area V Hight Image Level Acquiring Area Height 9 0 - 4095
8 Y Target Level Target Value of Y Level Adj. 217 0 - 255
9 Cb Target Level Target Value of Cb Level Adj. 212 0 - 255
10 Cr Target Level Target Value of Cr Level Adj. 212 0 - 255
11 Gain Tolerance Torelance of Level Adj. 1 0 - 255
12 Delta Gain Deviation Width of Gain Value 9 0 - 255
