Sanyo PLC-XW55A Service Manual

-20-
● : Adjustment necessary ❍ : Check necessary
Adjustments after Parts Replacement
Adjustments
Disassembly / Replaced Parts
LCD/
Prism Ass’y
Integrator
Lens (OUT)
Relay
Lens (OUT)
Polarized Glass
Power Board Main Board
R G B
Optical
Adjustments
Contrast Adjustment
G-Contrast adjustment
●
B-Contrast adjustment
●
Integrator lens adjustment
❍ ●
Relay lens-out adjustment
❍ ●
Electrical Adjustments
Panel type check and setting
● ●
Fan control adjustment
● ●
Pedestal adjustment [PC]
●
Gain adjustment [PC]
●
Pedestal adjustment [1080i]
●
Gain adjustment [1080i]
●
Gain adjustment [Video]
●
Black reference adjustment
●
Common center adjustment
● ●
50% white adjustment [PC]
● ●
White balance adjustment [PC]
❍ ❍
50% white adjustment [Video]
● ●
White balance adjustment [Video]
❍ ❍
White uniformity adjustment
❍ ❍
