KR6-XW55A00, KP6-XW50A00
-57-
Electrical Parts List
Electrical Parts Location
● Assemblied Boards
SW902
Thermal Switch
FN904
Cooling Fan
MSW Board
Filter Board
A901
Ballast Board
R/C Board
FN902
Cooling Fan
LP900
Lamp Ass’y
LF901
Noise Filter
Power Board
FN901
Cooling Fan
● Out Of Circuit Board
Main Board
SP901
Speaker
FN903
Cooling Fan
