Sanyo PLC-XW55A Service Manual

KR6-XW55A00, KP6-XW50A00
-80-
Mechanical Parts List
CABINET PARTS
C01 910 330 4237 ASSY,STAND LEG-N2PA
C02 910 330 4657 BUTTON CONTROL-KR6AC
C03 610 337 0729 CABINET TOP SERVICE-KR6AD
C04 910 330 4114 CABINET BOTTOM-KR6AC
C05 610 332 7051 COVER ,LP SERVICE-KR6AC
C06 910 330 4350 COVER LENS-KR6AC
C07 910 330 4244 DEC INLAY LED-KR6AC
C08 910 330 4329 DEC INLAY RC-KR6AC
C09 910 325 2477 DEC LEG-PT5EC
C10 910 325 2033 FILTER BASE B-PT5EC
C11 910 325 1982 FILTER BASE F-PT5EC
C12 910 330 9379 HOLDER COVER LENS-KR6AC
C13 610 335 6648 PANEL AV-KR6AD
CHASSIS PARTS
M01 910 330 4602 HOLDER POWER PCB-KR6AC
M02 910 330 4558 HOLDER LAMP FAN-KR6AC
M03 910 330 4121 MOUNTING DUCT TOP#PNL-KR6AC
M04 910 330 4503 MOUNTING DUCT TOP#POL-KR6AC
M05 910 330 4435 MOUNTING DUCT TOP-KR6AC
M06 910 330 4107 MTG DUCT BTM,LAMP-KR6AC
M07 910 330 4299 MTG DUCT TOP,LAMP-KR6AC
M08 910 330 4510 MTG DUCT TOP,OPTICAL-KR6AC
M09 610 331 8479 SPACER SHEET#POWER T-KR6AC
M10 910 329 6587 OPTICAL BASE BTM-KR6AC
M11 910 329 6709 OPTICAL BASE TOP-KR6AC
SCREWS
S01 411 031 9304 SCR BIN 3X8
S02 412 074 9900 SPECIAL SCREW
S03 411 189 6507 BOLT HEX-SCT+SW+W 2.5X5
OPTICAL PARTS
L01 645 089 9423 ASSY,LENS,CONDENSER(R)
L02 610 331 7359 ASSY,LCD PNL/PSM -KR6AC
(Including Key No. L02-1 to L012-4 and LCD Panels)
L02-1 945 086 6150 POLARIZED GLASS(OUT/G)
L02-2 945 086 6167 POLARIZED GLASS(OUT/B)
645 093 1185 POLARIZED GLASS(OUT/B)
L02-3 945 088 7988 PREPOLARIZED GLASS(OUT/G)
L02-4 945 088 7995 PREPOLARIZED GLASS(OUT/B)
L03 645 093 1314 LENS,PROJECTION
945 086 6105 LENS,PROJECTION
L04 945 086 6280 LENS,INTEGRATOR(IN)
L05 945 086 6297 LENS,INTEGRATOR(OUT)
For Model PLC-XW55A
L05 645 089 3124 LENS,INTEGRATOR(OUT)NC
For Model PLC-XW50A
L06 945 086 6310 LENS,CONDENSER(OUT)
L07 945 086 6327 LENS,CONDENSER(G,B)
L08 945 086 6341 LENS,RELAY(IN)
L09 945 086 6358 LENS,RELAY(OUT)
L10 945 086 6228 MIRROR(B)
L11 945 086 6235 MIRROR(R)
L10 645 089 9072 MIRROR(B)
L11 645 089 9089 MIRROR(R)
L12 945 086 6372 PRISM(PBS)
L13 945 086 6129 POLARIZED GLASS(IN/G)
L14 945 086 6136 POLARIZED GLASS(IN/B)
L15 945 086 6266 DICHROIC MIRROR (B)
L16 945 086 6273 DICHROIC MIRROR (G)
Key No. Part No. Description
Key No. Part No. Description
Mechanical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
