KR6-XW55A00, KP6-XW50A00
Electrical Parts List
-58-
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Key No. Part No. Description Key No. Part No. Description
ASSEMBLED BOARDS
FOR CHASSIS NO. KR6-XW55A00
! 655 001 9028 ASSY,PWB,MAIN KR6AD
! 655 001 9059 ASSY,PWB,R/C KR6AD
!OR 655 001 9271 ASSY,PWB,R/C KP6AD
! 655 001 9066 ASSY,PWB,POWER
! 655 001 9042 ASSY,PWB,FILTER
! 655 001 9011 ASSY,PWB,MSW
FOR CHASSIS NO. KP6-XW50A00
! 655 001 9257 ASSY,PWB,MAIN KP6AD
! 655 001 9059 ASSY,PWB,R/C KR6AD
!OR 655 001 9271 ASSY,PWB,R/C KP6AD
! 655 001 9066 ASSY,PWB,POWER
! 655 001 9042 ASSY,PWB,FILTER
! 655 001 9011 ASSY,PWB,MSW
OUT OF CIRCUIT BOARD
L601B 645 090 3830 CORE,FERRITE(BEAD)
L604 645 063 6905 CORE,CLAMP
L605 945 023 4959 CORE,CLAMP
! LF901 945 078 6472 UNIT,NOISE FILTER
! LP900 610 330 4564 LAMP, POA-LMP107
910 296 5804 STOPPER WIRE SEN MJ6A
645 090 3830 CORE,FERRITE(BEAD)
652 002 3505 SOCKET,HOUSING 3P
652 002 2249 TERMINAL,SOCKET
! A901 945 086 0981 UNIT,BALLAST
A901A 652 002 3390 CORD,ID-CONNECTOR
! FN901 945 079 2145 MOTOR,BLW DC 2.76W
! FN902 945 087 8931 MOTOR,FAN DC 3.12W
! FN903 945 079 2145 MOTOR,BLW DC 2.76W
! FN904 945 079 2145 MOTOR,BLW DC 2.76W
SP901 652 002 3055 SPEAKER,8
! SW902 945 079 2527 SWITCH,THERMAL(105DEG)
WK8D-28D 652 002 1426 CORD,ID-CONNECTOR
Z690&8S 652 002 0221 CORD,ID-CONNECTOR
Z6B&6C 652 002 3659 NON STANDARD WIRE
Z6D&CB1 652 002 1617 NONSTANDARD WIRE ASSY
Z6S&SW 652 002 0337 NONSTANDARD WIRE ASSY
Z8H&CB2 652 002 1419 NONSTANDARD WIRE ASSY
ZSP&8F 652 002 1686 NON STANDARD WIRE ASSY-JPN
FOR CHASSIS NO. KR6-XW55A00
655 001 9028 ASSY,PWB,MAIN KR6AD
FOR CHASSIS NO. KP6-XW50A00
655 001 9257 ASSY,PWB,MAIN KP6AD
TRANSISTOR
Q1003 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1004 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1006 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1007 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1301 305 217 8515 TR RSQ025P03-TR
Q2031 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3051 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3581 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3582 305 002 8327 TR 2SA1203-Y-TE12L
Q3601 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3801 305 191 5814 TR 3LN01C-TB-E
Q4011 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
To Next Page
