Sanyo PLC-XW55A Service Manual

-32-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
31 OSD (Pattern Selection) 0 0 - 7
32 GAMMA(ON/OFF) 1 0 - 1
33 ref_gate_pos (NRS Position) 43 0 - 1023
34 ref_gate_dur (NRS Width) 188 0 - 1023
35 gray_on 7 0 - 7
36 Compensations 0 0 - 1
37 Crosstalk Compensation EN 0 0 - 1
38 V-Line Shading DC Offset Comp. EN Normal-Mount / Rear-Ceiling 0 / 0 0 - 1
39 V-Line Shading Offset Comp. EN Normal-Mount / Rear-Ceiling 1 / 1 0 - 1
40 V-Line Shasing BLSP_EN Normal-Mount / Rear-Ceiling 1 / 1 0 - 1
41 Sequetial Ghost Compensation EN Normal-Mount / Rear-Ceiling 1 / 1 0 - 1
42 Block Ghost Comp. EN 0 0 - 1
43 Reverse Ghost Comp. EN 0 0 - 1
44 Back crosstalk Comp. EN 0 0 - 1
45 R_base_pos 4 0 - 15
R and B linked to G
46 G_base_pos 4 0 - 15
47 B_base_pos 4 0 - 15
48 RGB_adjust 0 0 - 7
49 RGB_level 0 0 - 1023
50
V-Line Shading Comp. Value
Setting [R0]
Normal-Mount / Rear-Ceiling 7 / 7 0 - 255
51
V-Line Shading Comp. Value
Setting [R1]
Normal-Mount / Rear-Ceiling 3 / 3 0 - 255
52
V-Line Shading Comp. Value
Setting [R2]
Normal-Mount / Rear-Ceiling 1 / 2 0 - 255
53
V-Line Shading Comp. Value
Setting [R3]
Normal-Mount / Rear-Ceiling 0 / 1 0 - 255
54
V-Line Shading Comp. Value
Setting [R4]
Normal-Mount / Rear-Ceiling 253 / 253 0 - 255
55
V-Line Shading Comp. Value
Setting [G0]
Normal-Mount / Rear-Ceiling 7 / 7 0 - 255
56
V-Line Shading Comp. Value
Setting [G1]
Normal-Mount / Rear-Ceiling 3 / 3 0 - 255
57
V-Line Shading Comp. Value
Setting [G2]
Normal-Mount / Rear-Ceiling 1 / 2 0 - 255
58
V-Line Shading Comp. Value
Setting [G3]
Normal-Mount / Rear-Ceiling 0 / 1 0 - 255
59
V-Line Shading Comp. Value
Setting [G4]
Normal-Mount / Rear-Ceiling 253 /253 0 - 255
60
V-Line Shading Comp. Value
Setting [B0]
Normal-Mount / Rear-Ceiling 7 / 7 0 - 255
61
V-Line Shading Comp. Value
Setting [B1]
Normal-Mount / Rear-Ceiling 3 / 3 0 - 255
62
V-Line Shading Comp. Value
Setting [B2]
Normal-Mount / Rear-Ceiling 1 / 2 0 - 255
63
V-Line Shading Comp. Value
Setting [B3]
Normal-Mount / Rear-Ceiling 0 / 1 0 - 255
64
V-Line Shading Comp. Value
Setting [B4]
Normal-Mount / Rear-Ceiling 253 / 253 0 - 255
65 Ghost_R_pos (Sequential) 4 0 - 15
66 Ghost_G_pos (Sequential) 4 0 - 15
67 Ghost_B_pos (Sequential) 4 0 - 15
68 Ghost_R_center 5 0 - 2047
69 Ghost_R_start 128 0 - 255
70 Ghost_R_end 128 0 - 255
71 Ghost_G_center 5 0 - 2047
72 Ghost_G_start 128 0 - 255
73 Ghost_G_end 128 0 - 255
74 Ghost_B_center 5 0 - 2047
75 Ghost_B_start 128 0 - 255
76 Ghost_B_end 128 0 - 255
77 R-Block Ghost 3 0 - 2047
78 G-Block Ghost 3 0 - 2047
79 B-Block Ghost 3 0 - 2047
80 R_base_level (Block) 0
81 G_base_level (Block) 0
82 B_base_level (Block) 0
83 Ghost_R_pos (Reverse) 3 0 - 2047
84 Ghost_G_pos (Reverse) 3 0 - 2047
85 Ghost_B_pos (Reverse) 3 0 - 2047
86 R_base_level (Reverse) 0 0 - 1023
87 G_base_level (Reverse) 0 0 - 1023
88 B_base_level (Reverse) 0 0 - 1023
89 C_TALK R 1022 0 - 1023
