Sanyo PLC-XW55A Service Manual

Key No. Part No. Description Key No. Part No. Description
KR6-XW55A00, KP6-XW50A00
Electrical Parts List
-60-
305 173 9915 TR 2SC3928A1S
Q5332 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q5333 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q5334 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q5336 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q5701 305 217 5019 TR RN1117 TE85L
Q5702 305 217 5019 TR RN1117 TE85L
Q6841 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6842 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6843 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6844 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6861 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q6862 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q7801 305 217 5019 TR RN1117 TE85L
Q7811 305 217 5019 TR RN1117 TE85L
Q7812 305 217 8515 TR RSQ025P03-TR
Q7813 305 139 7719 TR IMZ1A-T108
Q7862 305 217 8515 TR RSQ025P03-TR
Q7864 305 139 7719 TR IMZ1A-T108
Q9881 305 191 5814 TR 3LN01C-TB-E
INTEGRATED CIRCUIT
IC1302 310 479 4004 IC TC7WBD125AFK
IC1303 310 479 4004 IC TC7WBD125AFK
IC1306 309 553 4712 IC PQ070XZ02ZP
IC1307 309 553 4712 IC PQ070XZ02ZP
IC1308 309 531 6229 IC FA7701V-TE1
IC1371 310 538 4907 IC 24LC64T-I/SNG
IC301 309 670 8419 IC PW190-10L
IC3501 309 246 9710 IC LA6358NM-TE-L
IC3531 309 458 3414 IC M62393FP
IC3541 309 545 5710 IC XC6202P502M
IC3801 309 652 0714 IC HIN202EIBNZ-T
IC4071 309 428 8428 IC TC7WT125FU-TE12L
IC4891 309 404 7213 IC TC7SET00FU-(TE85L)
IC491 309 555 6417 IC SI-3018KS-TL
IC5001 309 564 1519 IC NJW1141M
IC5031 309 594 1916 IC LM4889MM
IC5081 309 398 1914 IC L88MS05TL-TL
IC5201 309 462 0327 IC 24LC21AT/SN
IC5202 310 517 6809 IC TC74LVX4053FT
IC5302 309 439 8919 IC TC7WH125FU
IC5601 309 416 6518 IC BA05FP-E2
309 591 8611 IC BA50BC0FP
309 673 6313 IC TA4805AF
IC5631 309 553 4712 IC PQ070XZ02ZP
IC5642 309 497 6315 IC BA09FP-E2
409 678 1815 IC TA4809AF
IC5701 309 461 7822 IC PQ20WZ11
IC7811 309 675 1316 IC FA7703V-H1
IC801 410 619 4205 IC S29GL032A90TFIR30KR6AC
IC841 310 616 3402 IC PST413A300NR
IC8811 309 481 8615 IC LM76CHMX-5
IC8821 309 481 8615 IC LM76CHMX-5
IC891 310 337 0605 IC HD74LVC14T
IC9882 309 464 1411 IC TC74ACT14FT
CAPACITOR
C1006 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C1007 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C1008 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C1009 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C1011 303 454 0415 CERAMIC 0.068U K 16V
