Page #64 background image
Key No. Part No. Description Key No. Part No. Description
KR6-XW55A00, KP6-XW50A00
Electrical Parts List
-64-
C4808 303 384 4712 TA-SOLID 47U M 6.3V
303 449 1212 POS-SOLID 47U M 6.3V
C4891 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C491 303 453 7613 CERAMIC 0.01U Z 50V
303 320 1317 CERAMIC 0.01U Z 50V
C492 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C493 303 401 2219 ELECT 100U M 6.3V
303 424 0315 ELECT 100U M 6.3V
C494 303 381 5217 ELECT 220U M 6.3V
303 423 6110 ELECT 220U M 6.3V
C5001 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5002 303 454 0613 CERAMIC 0.01U K 50V
C5003 303 454 0613 CERAMIC 0.01U K 50V
C5004 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5006 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5007 303 454 0613 CERAMIC 0.01U K 50V
C5008 303 454 0613 CERAMIC 0.01U K 50V
C5009 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C501 303 384 4712 TA-SOLID 47U M 6.3V
303 449 1212 POS-SOLID 47U M 6.3V
C5011 303 283 5711 CERAMIC 2200P K 50V
C5012 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5013 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C5014 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C5016 303 283 5711 CERAMIC 2200P K 50V
C5017 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5018 303 279 4315 CERAMIC 0.33U K 16V
C5019 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C502 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C5021 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C5022 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C5023 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C5024 303 379 6714 CERAMIC 10U K 16V
C5031 303 323 8818 CERAMIC 2.2U Z 16V
C5032 303 314 5918 CERAMIC 0.47U K 16V
C5033 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C5037 303 454 1412 CERAMIC 1U Z 10V
303 442 2018 CERAMIC 1U Z 10V
C5038 303 454 0613 CERAMIC 0.01U K 50V
C5039 303 454 0613 CERAMIC 0.01U K 50V
C504 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5041 303 454 0613 CERAMIC 0.01U K 50V
C505 303 381 5316 ELECT 100U M 16V
303 369 3211 ELECT 100U M 16V
C506 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5061 303 391 5511 ELECT 10U M 16V
303 175 7212 ELECT 10U M 16V
C5069 303 391 5511 ELECT 10U M 16V
303 175 7212 ELECT 10U M 16V
C508 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5081 303 379 6714 CERAMIC 10U K 16V
C5083 303 394 1312 ELECT 100U M 6.3V
303 387 4917 ELECT 100U M 6.3V
C5084 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C5086 303 394 1312 ELECT 100U M 6.3V
303 387 4917 ELECT 100U M 6.3V
C5087 303 394 9318 ELECT 220U M 6.3V
303 387 5112 ELECT 220U M 6.3V
C5088 303 394 9318 ELECT 220U M 6.3V
303 387 5112 ELECT 220U M 6.3V
C509 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C511 303 164 0217 CERAMIC 0.1U Z 25V
C512 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C513 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C514 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C518 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C519 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5201 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C5202 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C5203 303 368 7319 CERAMIC 10U K 6.3V
C521 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C522 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C524 303 453 8511 CERAMIC 1000P K 50V
303 454 1214 CERAMIC 1000P K 50V
C525 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
C5301 303 384 4712 TA-SOLID 47U M 6.3V
303 449 1212 POS-SOLID 47U M 6.3V
C5304 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
C531 303 384 4712 TA-SOLID 47U M 6.3V
303 449 1212 POS-SOLID 47U M 6.3V
C5310 303 384 4712 TA-SOLID 47U M 6.3V
303 449 1212 POS-SOLID 47U M 6.3V
C5313 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C5314 303 433 1112 CERAMIC 1U K 10V
C5317 303 433 1112 CERAMIC 1U K 10V
C532 403 461 3710 CERAMIC 0.1U Z 25V
303 454 0514 CERAMIC 0.1U Z 25V
303 343 3718 CERAMIC 0.1U Z 25V
C533 303 381 5316 ELECT 100U M 16V
303 369 3211 ELECT 100U M 16V
C5331 303 355 9913 CERAMIC 2.2U K 10V
C5332 303 433 1112 CERAMIC 1U K 10V
