Sanyo PLC-XW55A Service Manual

Key No. Part No. Description Key No. Part No. Description
KR6-XW55A00, KP6-XW50A00
-73-
Electrical Parts List
R637 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R639 301 256 2613 MT-GLAZE 2.4K JA 1/10W
R641 301 256 7212 MT-GLAZE 18K JA 1/10W
R646 301 150 5918 MT-GLAZE 10K JA 1/10W
R647 301 256 5911 MT-GLAZE 2.7K JA 1/10W
R648 301 256 3610 MT-GLAZE 15K JA 1/10W
R653 301 264 1912 MT-GLAZE 10K FA 1/10W
R654 301 265 3014 MT-GLAZE 560 FA 1/10W
R655 301 265 3915 MT-GLAZE 6.2K FA 1/10W
R656 301 256 0312 MT-GLAZE 820 JA 1/10W
R657 301 150 6212 MT-GLAZE 1K JA 1/10W
R658 301 150 6212 MT-GLAZE 1K JA 1/10W
R659 301 150 6212 MT-GLAZE 1K JA 1/10W
R660 301 162 3711 MT-GLAZE 4.7K JA 1/10W
VARIABLE RESISTOR
VR611 952 000 0385 VR,SEMI,1K N
TRANSFORMER
! T651 945 077 6312 TRANS,POWER,PULSE
945 083 6948 TRANS,POWER,PULSE
COIL
! L611 945 077 6572 LINE FILTER
L612 645 089 8952 INDUCTOR,900U
645 089 8969 INDUCTOR,1400U
DIODE
D611 307 191 3903 DIODE FML-G16S
D612 307 164 4015 DIODE RB160L-40-TE25
307 149 6327 DIODE SFPB-54V
D616 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D617 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D618 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D619 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D62R 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS35
D631 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D633 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
D636 407 256 3213 DIODE CRF03(TE85L)
D651 307 202 9801 DIODE FMB-26L
307 253 7504 DIODE RB085T-60
D652 307 202 9801 DIODE FMB-26L
307 253 7504 DIODE RB085T-60
D653 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
DB611 307 202 7708 DIODE D10XB60
MISCELLANEOUS
FB611 910 244 3975 CORE
FB613 910 244 3975 CORE
FB693 910 244 3975 CORE
FB694 945 041 1978 INDUCTOR,330 OHM
FB695 910 244 3975 CORE
! PC641 307 231 7700 PC TLP421F(D4-BL)
! PC643 307 231 7700 PC TLP421F(D4-BL)
PTH611 308 037 5501 THERMISTOR NTH11D5R0LC
PTH612 408 062 4606 TH PRF18BE471QB1RB
655 001 9042 ASSY,PWB,FILTER
CAPACITOR
! C601 304 088 8805 MT-POLYEST 0.22U M 275V
304 104 9601 MT-POLYEST 0.22U K 275V
304 104 9700 MT-POLYEST 0.22U M 275V
! C602 304 088 8805 MT-POLYEST 0.22U M 275V
304 104 9601 MT-POLYEST 0.22U K 275V
304 104 9700 MT-POLYEST 0.22U M 275V
C603 304 073 5109 CERAMIC 470P K 250V
C604 304 073 5109 CERAMIC 470P K 250V
RESISTOR
! R601 302 105 6803 OXIDE-MT 240KJA 1W
VARIABLE RESISTOR
! VA601 407 255 6304 VARISTOR MYG3-14K300ZT
308 061 5607 VARISTOR ENE471D-14A-S6
TRANSFORMER
! T601 945 050 2232 LINE FILTER
MISCELLANEOUS
! F601 323 021 7804 FUSE 250V 6.3A
655 001 9011 ASSY,PWB,MSW
SW901 945 063 8078 SWITCH,PUSH 2P-2TX3
PACKING MATERIALS
610 335 4842 CARTON CASE-KR6AD
For Model PLC-XW55A
610 335 4835 CARTON CASE-KP6AD
For Model PLC-XW5A
610 335 4859 CUSHION SPACER-KR6AD
610 335 4811 CUSHION LEFT-KR6AD
610 335 4958 CUSHION RIGHT-KR6AD
945 068 6864 POLY BAG-0440X0480*NC
ACCESSORIES
OWNER’S MANUAL
INSTRUCTIONS MANUAL-KR6AD
610 335 0929 CD-ROM,OWNERS MANUAL-LR6AD
REMOTE CONTROL
945 086 4965 ASSY,REMOCON CXVM
910 321 4482 RC-BATTERY LID-CXTJ
AC CORD
US 645 093 3028 CORD,POWER-2.3MK,US
EU 645 093 2984 CORD,POWER-2.3MK,US
MISCELLANEOUS
645 093 1642 CABLE,INTERFACE VGA
