Sanyo PLV-Z5 - Duct Cover Removal; LCD Duct Top Removal

- 26 -
12
Duct cover removal.
1.Remove the screws-A(T3x8), remove the screw-B(M2x4), and remove the Duct cover.
A
B
A
A
A
A
Duct cover
LCD duct top
13
LCD duct top removal.
1.Remove the 4 screws-A(T3x10) and remove the LCD duct top.
Fig. 12
Fig. 13
Mechanical disassemblies
