2-2. Major Component Specifications
2-2-1. Indoor Unit
Indoor Unit SAP–DMRV93GJ
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Control PCB
Part No. POW-DMRV243GJ
Controls Microprocessor
Control circuit fuse 2.50V 3.15A
Flap Motor and Louver Motor
Type —
Model —
Rating —
Coil resistance (Ambient temp. 25°C) Ω —
Heat Exchanger Coil
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.6
Face area m
2
0.118
Fan & Fan Motor
Type Centrifugal fan
Q’ty … Dia. and length mm 2 … ø144/L162
Fan motor model … Q’ty KFG4X-51G5P-S
No. of poles … rpm (230V, High) 4 … 1009
Nominal output W 50
Coil resistance (Ambient temp. 20°C) Ω BRN – WHT: 141.0 ORG – YEL: 12.8
WHT – VLT: 37.7 YEL – BLK: 58.2
VLT – ORG: 21.0 BLK – PNK: 33.3
Safety devices Type Thermal protector
Operating temp. Open °C 130 ± 8
Close Automatic reclosing
Run capacitor µF 3.0
VAC 440
Remote Control Unit RCS-3MVPS4E
