4
2-2-2. Outdoor Unit
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Circuit Board Ass´y POW–C301A–A
Type Rotary (Hermetic)
Compressor model C–R240H5S 80669545
Nominal output W 2,400
Compressor oil ... Amount cc 4GSD–T or SAY–56T ... 1,350
Coil resistance (Ambient temp. 25°C) Ω C – R : 0.944
C – S : 1.732
Type Internal protector
Safety
Overload relay —
devices Operating temp. Open °C Automatic opening
Close °C Automatic reclosing
Operating amp.(Ambient temp. 25°C) —
Run capacitor ... Q´ty µF 35.0 ... 2
VAC 400 ... 2
Crank case heater —
Type Propeller
Q´ty ... Dia. mm 1 ... ø 460
Fan motor model ... Q´ty KFC6S–91D5P–S ... 1
No. of poles .... rpm (240V, High) 6 ... 780
Nominal output W 90
Coil resistance (Ambient temp. 20°C) Ω WHT – BRN : 129.0
WHT – YEL : 57.4
YEL – PNK : 22.1
Safety
Type Thermal protector
devices Operating temp. Open °C 130 ± 8
Close Automatic reclosing
Run capacitor µF 6.0
VAC 440
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.8
Face area m
2
0.630
External Finish Acrylic baked-on enamel finish
Heat
Exch. Coil
CompressorFan & Fan Motor
Outdoor Unit SAP–C302A
To Next Page
