2-3. Other Component Specifications
5
Fuse Cartridge type
Rating / Size 250V, 20A / ø6.4 x 30mm
Power Relay (PR) EL1U
Coil rating AC 200–240V, 50/60Hz
Contact rating AC 277V, 30A
Thermistor (Air sensor) PBC–41E–S14
Resistance kΩ –20°C 40.1± 5% 20°C 6.5 ± 5%
–10°C 24.4 ± 5% 30°C 4.4 ± 5%
0°C 15.3 ± 5% 40°C 3.0 ± 5%
10°C 9.9 ± 5% 50°C 2.1± 5%
Thermistor (Room sensor) DTN-TKS128B
Resistance kΩ 25°C 5.0 ± 3%
Thermistor (Coil sensor) DTN-TKS131B
Resistance kΩ 0°C 15.0 ± 2%
Transformer (TR) ATR-J105
Rating Primary AC 230V, 50/60Hz
Secondary 19V, 0.526A
Capacity 10VA
Coil resistance Ω (at 21°C) Primary (WHT – WHT): 205 ± 10%
Secondary (BRN – BRN): 2.0 ± 10%
Thermal cut-off temp. 150°C
To Next Page
