3
2-2. Major Component Specifications
2-2-1. Indoor Unit
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Part No. POW–K301A
Controls Microprocessor
Control circuit fuse 250 V – 3.15 A
Remote Control Unit RCS–3S4E–G
Type Cross-flow
Q´ty ... Dia. and length mm 1 ... ø100 / L847.4
Fan motor model ... Q´ty KFG4X–31B5P–S ... 1
No. of poles .... rpm (240V, High) 4 ... 1,270
Nominal output W 30
Coil resistance (Ambient temp. 20°C) Ω WHT – BRN : 103.3 WHT – VLT : 32.5
VLT – ORG : 75.5 ORG – YEL : 28.6
YEL – BLK : 18.9 BLK – PNK : 48.0
– : –
– : –
Safety
Type Thermal protector
devices Operating temp. Open °C 130 ± 8
Close Automatic reclosing
Run capacitor µF 1.0
VAC 440
Type Stepping motor
Model ... Q´ty MP24GA2 ... 2
Rating DC 12 V
Coil resistance (Ambient temp. 20°C) kΩ Each terminals (1–2, 1–3, 1–4, 1–5) : 400 ± 7%
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.3
Face area m2 0.214
Heat
Exch. Coil
Flap Motor
Fan & Fan Motor
Circuit
Board
Ass´y
Indoor Unit SAP–K302A
To Next Page
