Inputs - Sync-Wire
Input Output
National Time/Rauland
Rauland Digital
Dry Contact Closure 110VAC Interface or
240VAC Interface
24VAC Interface
16
17
110VAC Neutral 110VAC H ot
11
17
Dig Line +5V
24VAC Neutral 24VAC Hot
15 17
7 17
N.O.
COM
8
12
8 24 7
23 22
Dig Out +5V Out
