Sapling NTP 8000 Series - Inputs - Sync-Wire

17
The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
P. (+1) 215.322.6063
F. (+1) 215.322.8498
www.sapling-inc.com
Dry Contact Closure 110VAC Interface or
240VAC Interface
24VAC Interface
Inputs - Sync-Wire
59 Minute Correction
58 Minute Corrections 1–4
Dry Contact Closure 110VAC Interface or
240VAC Interface
24VAC Interface
16
17
110VAC Neutral 110VAC H ot
16
17
110VAC Neutral 110VAC H ot
24VAC Neutral 24VAC Hot
15 17
24VAC Neutral 24VAC Hot
15 17
7 17
N.O.
COM
8
12
7 17
N.O.
COM
8
12
