Span Adjustment
Waags_Just.eps
Front
External Adjustment
Note: Before carrying out calibration/adjustment work, allow the balance/scale to warm
up properly!
The external calibration/adjustment can be performed in various ways.
Only use calibrated weights!
1. As described in this manual,
2. or using the Sartorius MC1 Server (Version 4.4) or later) or the SARTOCAS
program for PCs and laptops).
- Make sure that the balance/scale operating menu is set to the code „1 9 1 -
e external calibration/adjustment accessible“ (see Page 13-14 „ Operating Menu
Settings“) or „1 9 7 - external adjustment/calibration/", the Access Lock Switch
has to be closed.
- If necessary, tare the balance/scale by pressing the t key. Press q to
activate the calibration/adjustment routine.
- The calibration weight required is displayed, (depending on the model, e.g.
CP4202S).
Caution! The balance/scale only accepts a weight that is within a tolerance range of
approx. 2% of the nominal value. Errors exceeding this tolerance range can only
be corrected using the SARTORIUS MC1 Server Software.
CP Balances/Scales with Draft Shields and Triangular Weighing Pans
Models: CP423S, CP323S, CP323P, CP153, GC2502
- Center the required weight (e.g. 200g/E2 depending on the model, e.g. CP423S)
on the weighing pan and close the draft shield.
- After the calibration weight has been stored, the balance will return to the
weighing mode.
– Menu »1 10 2 Calibration/Adjustment« calibration weight value will be displayed
first, then press q key.
CP Balances/Scales with Square Weighing Pan
Models: CP4202S, CP3202S, CP3202P, CP2202S, CP5202, GP3202
- Center the required weight (e.g. 2000g/E2 depending on the model, e.g.
CP4202S) on the weighing pan.
- After the calibration weight has been stored, the balance will return to the
weighing mode.
– Menu »1 10 2 Calibration/Adjustment« calibration weight value will be displayed
first, then press q key.
Eck_re_3.eps
Front
