Error Code Explanation
Err 01 Display format overfl ow, i.e., the value to be output
cannot be shown on the display.
Err 02 Zero point error at the start of the calibration/
adjustment function; caused by operating error
(balance not tared, or still loaded), or stability was
not reached, or by a deviation of the zero point
(adjust the preload).
Err 06 Internal calibration weight defective or not present.
Err 10 “Tare” key is blocked, with data in the tare
2 memory. (only for the application “2nd tare
memory”)
Err 11 Invalid data; cannot be stored in the tare 2 memory.
Err 22 Reference value in the counting or weighing in per-
cent application not permissible; cannot be stored.
Err 30 The print key was pressed, or an external print com-
mand (“<ESC> P”) was given, while the balance was
in the BPI mode.
Err 50 Temperature compensation (TC) converter error;
value measured by the TC circuit exceeds the tole-
rance range.
Err 53 Temperature compensation (TC) converter not
functioning; no value transmitted to the balance
processor from the TC circuit.
Err 54 The balance converter value of the A/D converter is
below the lower limit; the value measured by the
A/D converter is too low, or no value is measured.
Err 55 The balance converter value of the A/D
converter is above the upper limit; the value
measured by the A/D converter is too high.
Remedial Measures
Reset the balance operating menu with menu
code »9 -- 1 «, “Accessing the Balance Menu.”
First make sure there was no operating error. If the
balance still cannot be calibrated/adjusted, you must
follow the procedure in “Adjusting the Preload”; then
perform “External Calibration/Adjustment.”
Check the calibration weight operating system and, if
necessary, exchange the main PCB. With balances
check the menu code settings. The codes »1 9 3 « and
»1 9 4 « should be blanked out, otherwise, overwrite
these codes with the SARTORIUS MC1Server 4.9.
The tare functions are interlocked; once the data
in the tare 2 memory has been deleted, the tare key
will be accessible again.
The display value you tried to store is negative. Check
the load on the balance (tare container).
The weight of the reference sample is too low, or the
displayed value is negative. Check the load on the balance
(reference sample).
Set the balance back to SBI; this can be done
using the SARTORIUS MC1 Server 4.9.
Perform TC compensation using the MC1 Server.
If this does not suffi ce, proceed as described under
» ERR 53 «.
Check the TC sensors, the main PCB and the
connectionbetween the two. If necessary, proceed as
directed in “Exchanging the Main PCB,” or replace the TC
sensors.
Check the weighing system, the main PCB and the
connection between the two. If necessary, proceed
as directed in “Exchanging the Main PCB,” or see
„Repairing the Weighing System.”
Check the weighing system, the main PCB and
the connection between the two. If necessary, proceed
as directed in “Exchanging the Main PCB.”
40 |
Error Messages
