Menu Operation
This display is divided into two sections.
Line for Operating Status:
The operating status line indicates the
function of the current screen page. In
the Setup menu, the current menu path
is shown here.
Example for Setup, Language:
Input and Output Window:
This window contains either detailed
information (e.g., on the drying pro-
gram) or a select list. A selected item is
displayed inversely (white letters on a
black background). You can also enter
letters, numbers, and special characters
in this window when an input field
is active.
Example for Setup, Language:
The following symbol can also appear
the input/output window:
o indicates the currently active menu
setting
11
Parameter Settings
The MA45 has an operating menu for
finding and setting parameters. Each
menu has several levels.
Example: Working with the Setup
Menu
First of all, you need to find the menu
item for the parameter you wish to
configure:
§ Press the x and y keys until
SETUP is highlighted, then press u
to confirm
§ Use the x and y keys to move
back and forth between menu items on
a given level
§ To select an item or open a submenu:
Press the u key
Parameter Settings:
§ Press the x and y keys,
repeatedly if needed, until the desired
parameter is highlighted (inverse
display)
§ To select the parameter: Press u
Now you can configure the desired
setting.
To select a parameter setting:
§ Press the x and y keys,
repeatedly if needed, until the desired
setting is highlighted (inverse display)
To enter alphanumeric characters:
§ Press the x and y keys,
repeatedly if needed, until the desired
character is displayed (see page 9 for
details on alphanumeric input) and
press u to confirm
§ Confirm the setting: Press the u key
To go back to the previous (higher)
menu level:
§ Press the c key
Exit the Setup menu: Press the
c key
Data Output
The MA45 is equipped with an interface
port for connecting either
– a printer, or
– a computer
Printer
The data format for output to an
external printer is pre-configured
for generating ISO/GLP-compliant
printouts.
ISO: International Organization
for Standardization
GLP: Good Laboratory Practice
See “Data Output Functions” in the
chapter entitled “Operating the
Moisture Analyzer” for a detailed
description of data output options.
Interface Port
You may choose to connect a computer
rather than a printer to the interface
port.
See “Data Output Functions” in the
chapter entitled “Operating the
Moisture Analyzer” for a detailed
description of data output options.
