Data Output
There are three options for data output:
– Output to the moisture analyzer
– Output to an external printer (YDP02-0CE or YDP03-0CE)
– Output to a peripheral device (e.g., a computer) via the interface port
Output to the Moisture Analyzer Display
(Weights and Calculated Values)
The display is divided into 9 sections. Information about the weighing system, the
application being used and the sample weighed is output in the following sections:
– Drying program/Test status line
– Print symbol
– Bar graph
– Busy symbol
– Plus/minus sign
– Measured value/result
– Weight unit display
– Graphic symbol
– Function line
Drying Program/Test Status
This line shows information on the drying program:
– Program number
– Temperature data
– Shutoff parameter
– Current temperature and elapsed time
– Active test function with parameters
Print Symbol
The print symbol is shown in this section when the r key is pressed or at the start
and end of moisture analysis.
Bar Graph (Overview Display)
The bar graph shows the target weight with tolerance values (–20%, +20%).
The bar graph is displayed if you have selected ON for the “Initial weight” parameter
in the drying program.
Drying program/Test status line
Bar graph
Measured value/result
Function line
Plus/minus sign
Busy symbol
Weight
unit
display
Graphic symbol
Print symbol
