Purpose
The moisture analyzer has an interface
port for connecting an external printer
or computer (or other peripheral device).
External Printer
You can use an external printer to
generate printouts and to document
settings.
Computer
Analyses and calculated values can be
transmitted to a computer for further
evaluation and recording.
!Warning When Using Pre-wired
RS-232 Connecting Cables!
RS-232 cables purchased from other
manufacturers often have incorrect pin
assignments for use with Sartorius
weighing systems! Be sure to check the
pin assignments against the chart below
before connecting the cable, and
disconnect any lines marked “Internally
Connected” (e.g., pin 6). Failure to
do so may damage or even completely
ruin your weighing system and/or
peripheral device.
39
Available Features
Type of interface: Serial interface
Interface operating mode: Full duplex
Standard: RS-232
Transmission rates: 150; 300; 600; 1,200; 2,400; 4,800; 9,600; 19,200 baud
Number of data bits 7, 8 bit
Parity: None, odd, even
Number of stop bits: 1 or 2 stop bits
Handshake mode: Software, hardware 1 character
Operating mode: SBI, xBPI
1
)
Network address
2
): 0, 1, 2, [...], 30, 31
Data output format with SBI: 20 characters + CR LF
1
) xBPI operating mode: 9600 baud, 8 bits, odd parity, 1 stop bit
2
) Network address is valid only in the xBPI mode
Factory Settings for the SBI Operating Mode Parameters:
Transmission rate: 1,200 baud
Number of data bits 7 bits
Parity: Odd
Stop bits: 1 stop bit
Handshake: Hardware 1 character
Operating mode: SBI
Preparation
§ See pages 42 and 43 for the pin assignment chart and cabling diagram.
Interface Port
To Next Page
