Data Output Format
You can output the values, displayed
in the corresponding line for moisture
analysis values, and the weight unit
with or without a data ID code.
Example: With Data ID code
N + 3.4253 g
20 characters per line are output.
Data Input Format
If you have a computer connected to
the interface port on the moisture
analyzer, you can send the commands
“Esc P CR LF” to generate a printout.
Output Format with 20 Characters + CR LF
12345678910111213141516171819202122
IIIIII+*DDDDDDDD * UUUCRLF
*****– ........ ***
* ********
I: ID code character U: Unit symbol
*: Space CR: Carriage return
D: Digit or letter LF: Line feed
Error Codes
12345678910111213141516171819202122
Stat*****ERR*###****CRLF
*: Space # # #: Error code number
H: Overload
L: Underload
40
