33
Maintenance
Changing the Paper Roll
The paper rolls must have the following
specifications (see “Accessories”):
– Standard paper roll
– Wood-free paper, 60 g
– Width: 57.5 mm ± 0.5 mm
– Diameter: maximum 65 mm
– Open core diameter: minimum 8 mm
§ Lift the cover of the paper roll compartment
§ Pull out the roll holders from both sides of the roll core
as shown on the left
§ Remove the old roll core
$ Place the new paper roll on a flat surface
$ The beginning of the paper must be on the bottom and
pointing towards you
§ Hold the paper roll above the paper roll compartment
between thumb and index finger of one hand
§ Thread the paper through the slot underneath the ink
ribbon with your other hand
§ To transport the paper through the ink ribbon
cassette, press the key repeatedly, or hold it down
> The paper will be threaded into, then out of the ink
ribbon cassette
