03015/03017
28
Symbol description:
1） Continuity test selected
2） Diode test selected
3） Auto range mode activated
4） Relative value measurement mode activated
5） Data hold mode is activated
6） Negative sign
7） communication
8） DC
9 The battery used by the meter runs out of power and shall be replaced timely. Warning: To avoid false readings that can lead
to electric shock or personal injury, replace the batteries immediately when this symbol appears on the screen..
10） Units
mV、V Voltageunits
mV: Millivolt; V: Volt
1V=103mV
μA、mA、A Current unit
μA: microamp; mA: milliampere; A: Ampere
1A=103mA=106μA
Ω、kΩ、MΩ Resistance units
Ω: Ohm; kΩ: kiloohm; MΩ megohm
1MΩ=103kΩ=106Ω=109mΩ
nF、μF Capacitance units
nF: nanofarad; μF: microfarad
1F=106μF=109nF=1012pF
℃、℉ Units of temperature
° C: Celsius; ° F: Fahrenheit
f （℉）=32+1.8 x c （℃）
Hz、kHz、MHz Frequency units
Hz: Hertz; kHz: kilohertz; MHz: Megahertz
1MHz=103kHz=106Hz
% Duty cycle unit %: percent
Technical specifications：
General Specification：
Specification of fuse for " " jack:
03015: 440mA, 1,000V, minimum breaking current 20,000 mA
03017: 630mA, 1,000V, minimum breaking current 20,000 mA Specification of fuse for " " jack:
20A, 1,000V, minimum breaking current 20,000A
Display of 03015: 3 3/4-digit LCD display with a maximum reading of 3999
Display of 03017: 3 5/6-digit LCD display with a maximum reading of 5999
Overrange indication: " " appears on the LCD
Automatic negative polarity indication: ＂ ＂ appears on the LCD
Sampling rate: 2 to 3 times/sec （approximation）
Operating temperature: 0-40℃ , relative humidity: <75%
