03015/03017
29
Additional temperature coefficient: 0.2 × specified accuracy/℃ （<18℃ or >28℃）
Storage temperature: -10-50℃ , relative humidity: <85%
Operation altitude: 0 to 2000m
Power supply: 9V 6F22 battery （1 piece）
Low battery voltage indication: " " appears on the LCD
Size: 184X89X62 （mm）
Weight: about 440 g （including battery and sheath）
Technical specifications：
Accuracy is specified within one year after calibration; temperature: 18-28℃ ; relative humidity: <75%.
The form of the accuracy specification:
DC voltage：
Range
Resolution Accuracy
03015 03017
400mV 600mV 0.1mV ±（0.8%+5）
4V 6V 1mV
±（0.5%+5）
40V 60V 10mV
400V 600V 0.1V
1000V 1000V 1V ±（1.0%+5）
Input impedance: 10MΩ
Maximum input voltage: 1000VDC
Note: The accuracy of the 1,000V range is valid from 20% to 100% of the range.
AC voltage:
Range
Resolution Accuracy
03015 03017
4V 6V 0.1mV ±（0.8%+5）
40V 60V 1mV ±（1.0%+5）
