Satchwell IAC 600 - Analogue Reference Module; Flasher Module

PERMISSIBLE CONNECTIONS
OUTPUTS INPUTS
= Analogue –10,000 to 10,000
= Digital ON or OFF
Voltage signals 0 = 0V, 50 = 5V, 100 = 10V
Controller output signals 0 = off, 100 = full on
MODULES AND FUNCTIONS
Bubbleland
Symbol Module Range Default
REFERENCE MODULES
(
Cont.
)
ANALOGUE REFERENCE MODULE
x 12
This module
g
ives an analo
g
ue value output that can be set b
y
the
user. The output value can be scaled in the same wa
y
as on a scalin
g
module to allow input of values to a number of decimal places or in
different units. This would
g
enerall
y
be used for checkin
g
module
operation.
Reference Value
This parameter displa
y
s and allows the user to set the analo
g
ue output
value
BEFORE the scalin
g
has been calculated.
–10,000 to 10,000 –
Input Minimum Value
–32,000 to 32,000 0
Output Minimum Value
–10,000 to 10,000 0
Input Maximum Value
–32,000 to 32,000 100
Output Maximum Value
–10,000 to 10,000 100
FLASHER MODULE
x 1
(
The module ma
y
be placed on screen as often as re
q
uired
)
The Flasher module
g
ives a pulsed di
g
ital output the rate of which can
be set b
y
the user. As the rate is arbitrar
y
and will var
y
with the
controller workload, it should be used for non critical applications onl
y
.
Flash Rate
The flash rate is set in arbitrar
y
units 0 bein
g
the fastest and 100 the
slowest. The on and off times are of similar len
g
th.
0 to 100 5
DIGITAL ONE MODULE
x 1
(
The module ma
y
be placed on screen as often as re
q
uired
)
This module
g
ives a di
g
ital output that is alwa
y
s ON. This would
g
enerall
y
be used for checkin
g
module operation.
DIGITAL ZERO MODULE
x 1
(
The module ma
y
be placed on screen as often as re
q
uired
)
This module
g
ives a di
g
ital output that is alwa
y
s OFF. This would
g
enerall
y
be used for checkin
g
module operation.
POWER ON REFERENCE MODULE
x 1
(
The module ma
y
be placed on screen as often as re
q
uired
)
This module
g
ives a sin
g
le pulsed on di
g
ital output each time the
controller power is switched on or the controller is reset. This can be
used to enable a se
q
uence of events to occur each time power to the
controller is reinstated. These events could, for instance, be start up
dela
y
s etc. The output can be latched if re
q
uired.
05/98 13 - 24 DS 2.951A
