Satec PM130EH SERIES User Manual

13
- write 7576 to register 120
- write 7577 to register 121
- write 7136 to register 122
Reading from registers 0-2 will return the kWh reading in registers 0 (low word) and 1 (high word), and the
voltage reading in register 2.
Table 4-1 User Assignable Registers
Address Register contents Type
0 Assigned register #0 INT16
1
Assigned register #1 INT16
2
Assigned register #2 INT16
… …
…
119
Assigned register #119 INT16
Table 4-2 User Assignable Register Map
Address Register contents Type R/W Range
120 Mapped address for register #0 UINT16 R/W 256 to 65535
121
Mapped address for register #1 UINT16
R/W 256 to 65535
122
Mapped address for register #2 UINT16
R/W 256 to 65535
… …
…
… …
239
Mapped address for register #119 UINT16
R/W 256 to 65535

Satec PM130EH SERIES Specifications

General

Display	LCD
Frequency	50/60 Hz
Communication	RS-485, Modbus RTU
Digital Outputs	2 relay outputs
Data Logging	Yes
Measurement Type	Power, Energy, Harmonics
Current Input	1A or 5A
Mounting	Panel Mount
Power Supply	85-265V AC/DC
Digital Inputs	2
Analog Outputs	Up to 4
Operating Temperature	-20 to 70°C
Dimensions	96 x 96 mm
Weight	0.5kg
