Satec PM130EH SERIES User Manual

14
5 POWERMETER REGISTERS DESCRIPTION
5.1 Basic Data Registers Set
Table 5-1 Basic Data Registers
Address Parameter Type R/W Unit Scale
1
Con-
Low High version
256 Voltage L1/L12
5
UINT16 R V 0 Vmax LIN3
257 Voltage L2/L23
5
UINT16 R V 0 Vmax LIN3
258 Voltage L3/L31
5
UINT16 R V 0 Vmax LIN3
259 Current L1 UINT16 R A 0 Imax LIN3
260 Current L2 UINT16 R A 0 Imax LIN3
261 Current L3 UINT16 R A 0 Imax LIN3
262 kW L1 UINT16 R kW -Pmax Pmax LIN3
263 kW L2 UINT16 R kW -Pmax Pmax LIN3
264 kW L3 UINT16 R kW -Pmax Pmax LIN3
265 kvar L1 UINT16 R kvar -Pmax Pmax LIN3
266 kvar L2 UINT16 R kvar -Pmax Pmax LIN3
267 kvar L3 UINT16 R kvar -Pmax Pmax LIN3
268 kVA L1 UINT16 R kVA -Pmax Pmax LIN3
269 kVA L2 UINT16 R kVA -Pmax Pmax LIN3
270 kVA L3 UINT16 R kVA -Pmax Pmax LIN3
271 Power factor L1 UINT16 R 0.001 -1.000 1.000 LIN3
272 Power factor L2 UINT16 R 0.001 -1.000 1.000 LIN3
273 Power factor L3 UINT16 R 0.001 -1.000 1.000 LIN3
274 Total power factor UINT16 R 0.001 -1.000 1.000 LIN3
275 Total kW UINT16 R kW -Pmax Pmax LIN3
276 Total kvar UINT16 R kvar -Pmax Pmax LIN3
277 Total kVA UINT16 R kVA -Pmax Pmax LIN3
278 Neutral current UINT16 R A 0 Imax LIN3
279 Frequency UINT16 R 0.01Hz 45.00 65.00 LIN3
280 Maximum sliding window kW demand
4
UINT16 R/W kW -Pmax Pmax LIN3
281 Accumulated kW demand UINT16 R/W kW -Pmax Pmax LIN3
282 Maximum sliding window kVA demand
4
UINT16 R/W kVA -Pmax Pmax LIN3
283 Accumulated kVA demand UINT16 R/W kVA -Pmax Pmax LIN3
284 Max. ampere demand L1 UINT16 R/W A 0 Imax LIN3
285 Max. ampere demand L2 UINT16 R/W A 0 Imax LIN3
286 Max. ampere demand L3 UINT16 R/W A 0 Imax LIN3
287 kWh import (low) UINT16 R/W kWh 0 9999 NONE
288 kWh import (high) UINT16 R/W 10,000 kWh 0 9999 x10
4
289 kWh export (low) UINT16 R/W kWh 0 9999 NONE
290 kWh export (high) UINT16 R/W 10,000 kWh 0 9999 x10
4
291 +kvarh net (low)
2
UINT16 R/W kvarh 0 9999 NONE
292 +kvarh net (high)
2
UINT16 R/W 10,000 kvarh 0 9999 x10
4
293 -kvarh net (low)
3
UINT16 R/W kvarh 0 9999 NONE
294 -kvarh net (high)
3
UINT16 R/W 10,000 kvarh 0 999 x10
4
295 Voltage THD L1/L12
6
UINT16 R 0.1% 0 999.9 LIN3
296 Voltage THD L2/L23
6
UINT16 R 0.1% 0 999.9 LIN3
297 Voltage THD L3
6
UINT16 R 0.1% 0 999.9 LIN3
298 Current THD L1 UINT16 R 0.1% 0 999.9 LIN3
299 Current THD L2 UINT16 R 0.1% 0 999.9 LIN3
300 Current THD L3 UINT16 R 0.1% 0 999.9 LIN3
301 kVAh (low) UINT16 R/W kVAh 0 9999 NONE
302 kVAh (high) UINT16 R/W 10,000 kVAh 0 9999 x10
4
303 Present sliding window kW demand
4
UINT16 R kW -Pmax Pmax LIN3
304 Present sliding window kVA demand
4
UINT16 R kVA -Pmax Pmax LIN3
305 PF at maximum siding window kVA demand UINT16 R 0.001 -1.000 1.000 LIN3
306 Current TDD L1 UINT16 R 0.1% 0 100.0 LIN3
307 Current TDD L2 UINT16 R 0.1% 0 100.0 LIN3
308 Current TDD L3 UINT16 R 0.1% 0 100.0 LIN3

Satec PM130EH SERIES Specifications

General

Display	LCD
Frequency	50/60 Hz
Communication	RS-485, Modbus RTU
Digital Outputs	2 relay outputs
Data Logging	Yes
Measurement Type	Power, Energy, Harmonics
Current Input	1A or 5A
Mounting	Panel Mount
Power Supply	85-265V AC/DC
Digital Inputs	2
Analog Outputs	Up to 4
Operating Temperature	-20 to 70°C
Dimensions	96 x 96 mm
Weight	0.5kg
