Satec PM130EH SERIES User Manual

25
Trigger parameter Trigger Type Unit Limit/scale
1
Con-
ID Low High version
Negative phase rotation reversal
2
0x8902
UINT16 N/A N/A NONE
High/low real-time values on any phase
High voltage
4
0x0E00
UINT16 V 0 Vmax LIN3
Low voltage
4
0x8D00
UINT16 V 0 Vmax LIN3
High current
0x0E01
UINT16 A 0 Imax LIN3
Low current 0x8D01 UINT16 A 0 Imax LIN3
High voltage THD
5
0x0E07 UINT16 0.1% 0 999.9 LIN3
High current THD 0x0E08 UINT16 0.1% 0 999.9 LIN3
High K-Factor 0x0E09 UINT16 0.1 1.0 999.9 LIN3
High current TDD 0x0E0A UINT16 0.1% 0 100.0 LIN3
High/low real-time auxiliary values
High frequency
0x1002
UINT16 0.01Hz 0 100.00
3
LIN3
Low frequency
0x9002
UINT16 0.01Hz 0 100.00
3
LIN3
High/low average values per phase
High current L1
0x1103
UINT16 A 0 Imax LIN3
High current L2
0x1104
UINT16 A 0 Imax LIN3
High current L3
0x1105
UINT16 A 0 Imax LIN3
Low current L1
0x9103
UINT16 A 0 Imax LIN3
Low current L2
0x9104
UINT16 A 0 Imax LIN3
Low current L3
0x9105
UINT16 A 0 Imax LIN3
High/low average values on any phase
High voltage
4
0x1300
UINT16 V 0 Vmax LIN3
Low voltage
4
0x9200
UINT16 V 0 Vmax LIN3
High current
0x0301
UINT16 A 0 Vmax LIN3
Low current
0x8201
UINT16 A 0 Vmax LIN3
High/low average total values
High total kW import
0x1406
UINT16 kW -Pmax Pmax LIN3
High total kW export
0x1407
UINT16 kW -Pmax Pmax LIN3
High total kvar import
0x1408
UINT16 kvar -Pmax Pmax LIN3
High total kvar export
0x1409
UINT16 kvar -Pmax Pmax LIN3
High total kVA
0x1402
UINT16 kVA 0 Pmax LIN3
Low total PF Lag
0x9404
UINT16 0.001 0 1.000 LIN3
Low total PF Lead
0x9405
UINT16 0.001 0 1.000 LIN3
High/low average auxiliary values
High neutral current
0x1501
UINT16 A 0 Imax LIN3
High frequency
0x1502
UINT16 0.01Hz 0 100.00
3
LIN3
Low frequency
0x9502
UINT16 0.01Hz 0 100.00
3
LIN3
High present demands
High volt demand L1/L12
4
0x1600
UINT16 V 0 Vmax LIN3
High volt demand L2/L23
4
0x1601
UINT16 V 0 Vmax LIN3
High volt demand L3/L31
4
0x1602
UINT16 V 0 Vmax LIN3
High ampere demand L1
0x1603
UINT16 A 0 Imax LIN3
High ampere demand L2
0x1604
UINT16 A 0 Imax LIN3
High ampere demand L3
0x1605
UINT16 A 0 Imax LIN3
High block kW demand
0x1606
UINT16 kW 0 Pmax LIN3
High block kVA demand
0x1608
UINT16 kVA 0 Pmax LIN3
High sliding window kW
demand
0x1609
UINT16 kW 0 Pmax LIN3
High sliding window kVA
demand
0x160B
UINT16 kVA 0 Pmax LIN3
High accumulated kW demand
0x160F
UINT16 kW 0 Pmax LIN3
High accumulated kVA demand
0x1611
UINT16 kVA 0 Pmax LIN3
High predicted kW demand
0x1612
UINT16 kW 0 Pmax LIN3
High predicted kVA demand
0x1614
UINT16 kVA 0 Pmax LIN3
1
For parameter limits, see Note
1
to Table 5-1
2
The setpoint is operated when the actual phase sequence does not match the indicated phase rotation
