Chapter 2 Installation
Remote Display Installation
14
Series PM172 Powermeters
Remote Display Installation
Mechanical Installation
Standard Cutouts
(ANSI 4" round or DIN 92x92 mm square)
Figure 2-9 Display
cutout dimensions
STEP 1: Insert the display module into cutout.
STEP 2: Fasten washers and nut on screw
s.
Figure 2-10 AN
SI 4" or DIN 92x92 mm display mounting
Special Cutout
13
15
