Chapter 3 Display Operations Indicators and Controls
32 Series PM172 Powermeters
Chapter 3 Display Operations
Indicators and Controls
Display Diagnostics
The display may indicate a connection error as shown on the left picture if it
fails to establish a connection with the meter. Check the connection between
the display module and the meter body. If the error message is still
displayed, contact your local distributor.
Numeric LED Display
The meter has a simple user interface that allows you to view numerous
measurement parameters by scrolling through different display pages. The
Load Bar Graph
Wh/varh Pulse LED
Measurement Units
Port Activity LEDs
Navigation Buttons
Displayed Parameters
diSP
Con.Err
