5 Technical Specification
TRANSMISSION STANDARDS
DVB-S2/S, MPEG-2,MPEG-4, H.264
SATELLITE INPUT/DEMODULATION
Connector Type
F Type
Input Frequency
950 to 2150 MHz
Signal Input Level
- 65 to -25 dBm
Band Switch Control
22KHz
LNB Supply
13V/18V, IMax 400mA
Demodulation Type
QPSK,8PSK
Symbol Rate
2<Rs<45 M band(SCPC/MCPC)
LCD FEATURES
LCD Type
TFT TRANSMISSIVE
Number of Dots
320(RGB) x240
Active area (W x H)
70.08x52.56 mm
2
AV output interface
Connector Type
3.5 mm jack
Video Output
CVBS,
Audio output
Stereo Audio L/R output
AV input interface
Connector Type
3.5 mm jack
Video input
CVBS,
Audio input
Stereo Audio L/R input
AUDIO/VIDEO PROCESSING
Video decompression
MPEG-2 MP@HL, MPEG-1 Decoding,MPEG-4 ASP@L5 HD
resolution,H.264 MP&HP@L4,HW JPEG decoding
Resolving rate
PAL-25 frame@720*576,NTSC-30 frame@720*480,
Signal compatibility
Support conversion for different video formats
Video Format
4:3,16:9,By Pan & Scan and Letter Box conversion
Audio decompression
MPEG-1 Layer I/II ，MPEG-2 Layer I/II,
Audio output mode
Stereo, Mono, R/L
DATA SERVICE PORT
Connector
USB
Data protocol
USB2.0 interface

Satlink WS6922 Specifications

General

Brand	Satlink
Model	WS6922
Category	Measuring Instruments
Language	English
