SATO CL408-412e - Flash Memory Download Mode

Unit 4: Printer Configuration
CL408-412e Supplemental Manual
4-15 PN: 9001159A
FLASH MEMORY DOWNLOAD MODE
A Flash ROM internally stores/deletes font and custom designed character data. The data is sent from a host
system to the printer. Use the printer’s operator panel to select and enter the required options.
Refer to the Menu Definition Tables in the following chapter to provide an explanation of each menu screen.
Figure 4-10, Flash Memory Download Mode
Send data from
host system
PROGRAM DOWNLOAD
START > > > END
FLASH DOWNLOAD
READY
LINE FEED
No action,
no change
DSW6: ON
POWER
Download
completed
Printer
begins
receiving
data
No action,
no change
DOWNLOAD COMPLETE
PRESS FEED KEY
Power printer off,
reset DSW6 to exit
FEED LINE
No action,
no change
