SATO CL408-412e - Linerless Mode

Unit 6: Maintenance
CL408-412e Supplemental Manual
6-13 PN: 9001159A
Figure 6-9, Print Base Reference Position
LABEL PRINT DIRECTION
REFLECTIVE SENSORTRANSMISSION SENSOR
Base Print Position
CONTINUOUS MODE
REFLECTIVE SENSORTRANSMISSION SENSOR
Base Print & Tear-
Off Position
TEAR-OFF MODE
REFLECTIVE SENSORTRANSMISSION SENSOR
Base Print & Cut
Position
CUTTER MODE
Base Print Position
Base Print Position
REFLECTIVE SENSOR
TRANSMISSION SENSOR
Base Print &
Dispense Position
DISPENSE MODE
Base Dispense Position
Base Print Position
REFLECTIVE SENSOR
Base Cut Position
LINERLESS MODE
Base Print Position
