SATO CL4NX RIDF User Manual

3 Loading the Ribbon and Media
2 Push the ribbon rewind spindle w all the
way in.
If there is any ribbon on the ribbon rewind spindle,
remove it from the spindle before installing new
ribbon.
3 Push the head lock lever e towards the
rear.
4 Load the ribbon r onto the ribbon supply
spindle t.
While taking note of the wind direction, insert the
ribbon all the way in.
2
3
5
4

SATO CL4NX RIDF Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Width	4.09 inches (104 mm)
Print Resolution	203 dpi
Media Type	Roll, Fan-fold
Media Thickness	0.0024 - 0.01 inches
Ribbon Length	984 feet (300 m)
Processor	32-bit RISC processor
Interfaces	USB, RS-232C, Ethernet
RFID	Optional
Supported Barcode Types	1D, 2D
Power Supply	AC100V to 240V ± 10%, 50/60 Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	30 - 80% RH, non-condensing
Weight	33.07 lbs
