SATO CL4NX RIDF User Manual

3 Loading the Ribbon and Media
Loading Media
Use genuine SATO media and ribbons for the printer to ensure optimum print
quality.
CAUTION
• The print head and its
surroundings are hot after printing. DO NOT touch the print head after printing, as
this may result in burning or injury.
Loading Media Roll
The routing path of the media is shown in the right
picture.
When loading the media, make sure that the print side
is facing up.
1 Open the top cover.
CAUTION
Open the top cover fully to prevent accidental drop of
the cover.
2 Push the head lock lever towards the
rear to unlock the print head.
Face-in media
Face-out media

SATO CL4NX RIDF Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Width	4.09 inches (104 mm)
Print Resolution	203 dpi
Media Type	Roll, Fan-fold
Media Thickness	0.0024 - 0.01 inches
Ribbon Length	984 feet (300 m)
Processor	32-bit RISC processor
Interfaces	USB, RS-232C, Ethernet
RFID	Optional
Supported Barcode Types	1D, 2D
Power Supply	AC100V to 240V ± 10%, 50/60 Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	30 - 80% RH, non-condensing
Weight	33.07 lbs
