RT-TGP/RT-BT OWNER’S MANUAL
PARTS INVENTORY
Parts and Hardware Lists
PAGES:
5-10
IF YOU CANNOT FIND AN ITEM ON THIS LIST, CHECK THE MOUNTING
LOCATIONS OR EXAMINE THE PACKAGING MATERIALS VERY CAREFULLY.
CERTAIN COMPONENTS MAY HAVE BEEN PRE-INSTALLED FOR
SHIPPING PURPOSES.
27” x 16” Cast Iron Router Table
27” x 16” Cast Iron Router Table (1)
M6 x 1.0 Hex Nut (10)
M6 x 1.0 x 40 Flat Head
Phillips Screw (10)
A.
B.
C.
Please unpack the parts carefully and conrm you have received each item on the
list below.
You will also need the following tools to complete the
27” x 16” Cast Iron Router Table assembly:
• Phillips Head Screwdriver
See Exploded View #1 on page 49 for more information.
