RT-TGP/RT-BT OWNER’S MANUAL
Parts List 5: 27” Fence Assembly for Router Tables (RT-F27)
No. Description Part No. Qty.
N/A 27" Fence Assembly for Router Tables RT-F27 1
5.1 27" Router Table Fence RT-F27-001 1
5.2 Fence Lock Knob RT-F27-002 2
5.3 M8 x 23 x 2 Washer RT-F27-003 2
5.4 23mm Wide Lock Knob Nut RT-F27-004 2
5.5 Router Fence Glide Pad RT-F27-005 4
5.6 Fence Face Plate Lock Knob RT-F27-006 8
5.7 M6 x 16 x 2 Washer RT-F27-007 8
5.8 M6 x 1.0 x 35 T-Bolt RT-F27-008 8
5.9 27" Router Table Fence Ruler RT-F27-009 1
5.10 2 1/2 Inch Dust Port RT-F27-010 1
5.11 1/4"-20 x 3/4" Pan Head Phillips Screw RT-F27-011 2
5.12 1/4"-20 Square Nut RT-F27-012 2
5.13 Face Plate Spacer Bar RT-F27-013 2
5.14 Router Fence Face Plate RT-F27-014 2
5.15 Router Fence Guard RT-F27-015 1
5.16 Router Fence Guard Spacer RT-F27-016 2
5.17 Spring Pin (3mm x 10mm) RT-F27-017 4
