SCADAmetrics EtherMeter User Manual

11
METER HOOKUP FOR SENSUS-COMPATIBLE REGISTERS:
The following diagram demonstrates the hookup of a Sensus-compatible encoder register to
Meter Channel 1 of the EtherMeter. Terminals 14, 15, and 16 are used in this case. Hookup to
Meter Channel 2 will be identical, except terminals 17, 18, and 19 are used.
SERIAL
PORT
ETHERNET
PORT
SETUP
RUN RS-485
RS-232
120
OHM
TERM.
NO
TERM.
BACK
LIGHT
ON
BACK
LIGHT
OFF
FLASH PROGRAMMING HEADER
(INTERNAL)
################
################
M2-RX
M2-TX
M1-RX
M1-TX
DCD
XMT
RxD
TxD
PWR
JP1 JP2
ETHERNET
SERIAL
LCD DISPLAY
12345678910111213141516171819202122
LCD ADJ
EtherMeter™ AMR-Industrial Interface
scadametrics.com
ETHERMETER-100
PATENT PENDING
MAC ID:
00-1D-C8-nn-nn-nn
SENSUS-COMPATIBLE
ENCODER REGISTER
RG
B
PWR+ PWR- CANH CANL RESERVED
AIN1+ AIN1- AIN2+ AIN2-
AUX1+ AUX1- AUX2+ AUX2-
M1-TX
M1-RX
M1-CMN M2-TX M2-RX M2-CMN
485-A 485-B 485-CMN
AIN1:
ON=4-20mA
OFF=0-5V
AIN2:
ON=4-20mA
OFF=0-5V
(INTERNAL)
PRODUCT/MAC ID LABEL
