SCADAmetrics EtherMeter - ADAM-4000 Register Map

65
FUNCTION: #AAn (READ ANALOG INPUTS)*
REGISTERS (Hex) DESCRIPTORS
0 METER 1 TOTAL (UNSCALED)
1 METER 2 TOTAL (UNSCALED)
2 FLOW 1 X 1000
3 FLOW 2 X 1000
4 ROLLOVERS – METER 1
5 ROLLOVERS – METER 2
6 AIN 1 (0-10000)
7 AIN 2 (0-10000)
8 SUPPLY VOLTS X 10
9 DIGITAL STATUS BITS
A METER 1 READ FAULT
B METER 2 READ FAULT
C SYSTEM UPTIME (MINUTES)
*AA : HEX DEVICE ADDRESS
n : HEX INPUT CHANNEL (0-F)
FUNCTION: $AA6 (READ DISCRETE INPUTS)*
INPUTS DESCRIPTORS
0 AUXILIARY DIGITAL I/O 1
1 AUXILIARY DIGITAL I/O 2
2 AUXILIARY DIGITAL I/O 3
3 -reserved/future-
4 -reserved/future-
5 -reserved/future-
6 METER 1 READ FAULT
7 METER 2 READ FAULT
*AA : HEX DEVICE ADDRESS
FUNCTION: #AA1n0d (WRITE RELAY)*
COILS DESCRIPTOR
0 AUXILIARY DIGITAL OUTPUT 1
1 AUXILIARY DIGITAL OUTPUT 2
2 AUXILIARY DIGITAL OUTPUT 3
3-7 -reserved/future-
8 RESET CNT1 to ZERO (When Meter Ch. 1 Pulse Input)
9 RESET CNT2 to ZERO (When Meter Ch. 2 Pulse Input)
A-F -reserved/future-
*AA : HEX DEVICE ADDRESS
n : HEX COIL ADDRESS (0-F)
d : 1 (ON) or 2 (OFF)
FUNCTION: $AAM (READ DEVICE ID)*
RESPONSE: !AAETHERMETER<CR>
*AA : HEX DEVICE ADDRESS
EtherMeter ADAM-4000 Register Map.
