SCADAmetrics EtherMeter - ADAM-4000 Request;Response Example

67
Master (Request):
# 04 0 <CR>
EtherMeter (Response):
> 5 F 5 E 0 F 3 <CR>
START DELIMITER
ANALOG INPUT RESPONSE
DATA (METER 1 TOTAL)
MSG TERMINATION DELIMITER
ANALOG INPUT START DELIMITER
TARGET ADDRESS
ANALOG INPUT CHANNEL
END OF MSG DELIMITER
Example ADAM-4000 Request/Response.
Note the response, 5F5E0F3 hexadecimal, which corresponds to 99999987 decimal. Note
that all ADAM analog data is transmitted in hexadecimal format.
