Scaime eNod4-C - Page 11

11
SCAIME Manual : NU-eNod4C-E-0418-196712-F.docx
Logical inputs
Number
2(+2 with IO+ version)
Type
opto-insulated type 3
Low level voltage-current
0 / 5 VDC – 0 /1.5 mA
High level voltage-current
11 / 30 VDC – 2 / 9 mA
7 mA @ 24VDC
Logical outputs
Number
4
Type
solid state relay
Max. current @ 40°C
0,4
A
Max. voltage in open state
53 V
DC
or 37 V
AC
Max resistor in close state
2
Ω
Metrological specifications on A3 connector input (load-cell type sensor)
Input sensor range for a load cell sensor
 7.8
mV/V
Thermal zero drift typical
1.5
ppm/°C
Thermal span drift typical
2
ppm/°C
Linearity deviation
0.003
% FS
Conversion rate
6.25 ... 1920
meas./s
