2 ENOD4 PRODUCT RANGE
2.1 General presentation
eNod4 is a high speed digital process transmitter with programmable functions and powerful signal processing
capabilities. eNod4 offers operating modes for advanced process control both static and dynamic.
Quick and accurate:
• Analog to digital conversion rate up to 1920 meas/s with maximum scaled resolution of ±500 000 points.
• Digital filtering and measurement scaling.
• Measurement transmission up to 1 000 meas/s.
Easy to integrate into automated system:
• USB, RS485 and CAN communication interfaces supporting ModBus RTU, CANopen® and PROFIBUS-DPV1
(depending on version) communication protocols.
• Digital Inputs/Outputs for process control.
• Setting of node number by rotary switches and communication baud rate by dip switches.
• Integrated selectable network termination resistors.
• Wiring by plug-in terminal blocs.
2.2 Versions
2.2.1 Communication protocol versions
• Strain gauges load-cell conditioner with CANopen® and ModBus RTU communication.
• Strain gauges load-cell conditioner with Profibus DP-V1 and ModBus RTU communication.
• Strain gauges load-cell conditioner with Modbus TCP and ModBus RTU communication.
• Strain gauges load-cell conditioner with EtherNet/IP and ModBus RTU communication.
• Strain gauges load-cell conditioner with Profinet IO and ModBus RTU communication.
• Strain gauges load-cell conditioner with EtherCAT and ModBus RTU communication.
EDS, GSD, ESI and GSDML configuration files for above protocols can be downloaded from our web site:
http://www.scaime.com
2.2.2 IO+ version
In conjunction with all communication protocol versions, eNod4 can supports an opto-insulated board fitted with:
• 2 additional digital inputs and 1 speed sensor dedicated input.
• 0-5V or 0-10V analog output voltage.
• 4-20mA, 0-24mA, 0-20mA or 4-20mA with alarm at 3.6mA analog output current.
2.3 eNodView Software
So as to configure eNod4, SCAIME provides eNodView software tool. eNodView is the software dedicated to eNod
devices and digital load cell configuration from a PC. This simple graphical interface allows accessing the whole
functionalities of eNod4 for a complete setting according to the application.
eNodView features and functions:
• eNod4 control from a PC
• Calibration system
• Modification/record of all parameters
• Measure acquisition with graphical display
• Numerical filters simulation
• Frequential analysis FFT
• Process control
• Network parameter
eNodView software is available in English and French version and can be downloaded from our web site:
http://www.scaime.com or ordered to our sales department on a CD-ROM support.
