11 OUTPUTS FUNCTIONING
Each output can be individually set to positive or negative logic.
11.1 Outputs assignment:
Function
Functioning mode
transmitter
checkweigher
None
●
●
Set point
●
●
Motion
●
●
Defective measurement
●
●
Input image
●
●
Level on request
●
●
Cycle in progress
●
Checkweigher result available
●
Checkweigher result out of tolerances
●
Checkweigher result within tolerances
●
Checkweigher result out of high tolerance
●
Checkweigher result out of low tolerance
●
11.2 Description:
11.2.1 None:
The output has no function
11.2.2 Set point:
The outputs can be assigned to configurable set points. Output 1 is assigned to set point 1, output 2 to set point 2 and
so on.
Set points can be assigned to:
• gross measurement
• net measurement
• Checkweigher result
• Checkweigher total running
Set points and are defined by a high value, a low value and a functioning mode.
Two functioning modes are possible:
• Hysteresis
