Metrological specifications on analog output (IO+ version)
Output voltage range
0-5 or 0-10
V
Output current range
4-20, 0-24 ou 0-20
mA
Max. load on current output
500
Ohm
Outputs resolution
16
bit
Max. linearity error
1
LSB
Total error
+/- 0.07
%FSR
Thermal zero drift typical
+/- 2
ppm/°C
Thermal span drift typical
+/- 3
ppm/°C
Conversion rate
A/D converter rate value
Hz
Speed sensor power-supply (IO+ version)
Bridge excitation voltage (V+ …V-)
12.5 +/- 2
V
Bridge excitation current
30
mA
Isolation
1000
V
Speed sensor input (IO+ version)
IN5 HTL
0…2.5 / 5…30
VDC
IN5 TTL
0…0.5 / 2.4…5
VDC
Isolation
1000
V
3.3 Legal for trade
Characteristics
Unit
Accuracy class
III or IIII
Maximum number of weighing ranges
1
Maximum number of verification scale divisions
6000
Load cell(s) excitation voltage
5
V
Minimum voltage division per verification scale division
(ΔUmin)
0.5
µV
Minimum voltage of the weighing range
0.5 * n * 10
-3
mV
Maximum voltage of the weighing range
39
mV
Value of factor p
i
0.5
Minimum impedance for the load cell
47
Ohm
Type of load cell(s) connection system
4-wire or 6-wire
Maximum impedance for the load cell
1500
Ohm
Maximal length/section measurement cable
166
m/mm
