Analog output affectation function is common to both current and voltage output and might be assigned to followings:
• None: analog outputs have no function.
• Gross measurement: analog outputs can be assigned to gross measurement copy. Maximal level value is
related to Maximum Capacity parameter and works in mono-quadrant functioning. Bi-quadrant option can
only be applied to gross measurement copy. When this option is activated, the lowest value of current and
voltage levels corresponds to -MC and the highest value to +MC.
• Net measurement: analog outputs can be assigned to net measurement copy. Maximal value is related to
Maximum Capacity parameter and works in mono-quadrant functioning only. The highest value of current
and voltage levels corresponds to +MC in only one quadrant.
• Level on request: analog outputs are driven by master requests through the external value to control analog
output variable (in 0.01% of the full scale of current or voltage analog outputs).
When analog output is assigned to “Gross measurement” or “Net measurement” its value jumps to a special error value
when the internal alarm flag described in “Weighing diagnosis” § in the MEASUREMENT AND STATUS § is activated. This
allows to warn about defection of the measurement chain.
