Scaime eNod4-C - Page 58

58
SCAIME Manual : NU-eNod4C-E-0418-196712-F.docx
S (mV/V)
0 – 6.00000
Load cell sensitivity in mV/V at maximum capacity
Span Calibration correction
Span. cor
0.9 – 1.100000
Allows to adjust initial calibration
Calibration g
>0 (9.805470)
Allows compensating the gravity difference between
calibration place and using place.
Use g
>0 (9.805470)
