31
USE A STAR SCREWDRIVER TO UNSCREW THE
TWO SCREWS AT THE LOWER END
USING A SMALL SCREWDRIVER, LEVER UPWARDS
FROM ONE OF THE TWO BOTTONHOLES ON THE
BACK.
TO REMOVE THE TOP, REMOVE THE SCREW
CAPS WITH A SMALL SCREWDRIVER
IF SOME PARTS ARE DIRTY DUE TO FOOD OR LIQUID DIRTY STAINS, WE SUGGEST TO TAKE OFF HTE PLANE. THIS OPERATION SHALL PREVENT
DIRT FROM PRODUCING UNPLEASANT ODOURS AND OBSTRUCTING THE DRAIN PIPE. DON’t USE AGGRESSIVE PRODUCTS WHEN CLEANING
THE REFRIGERATED TANK. THIS OPERATION SHOULD BE CARRIED OUT BY A TECHNICIAN
CLEANING OF INSIDE PANE BASE AND TANK Models:
MITRA S-M-L PO
DOOR ADJUSTMENT
WITH AN ELECTRIC SCREWDRIVER OR A
SCREWDRIVER UNSCREW THE SCREWS TAKING
CARE NOT TO SCRATCH THE GRID
THE GRID SHALL BE REMOVED, TILTED IT
SLIGHTLY OUT AND RAISED
TO INSPECT THE REFRIGERATION SYSTEM,
REMOVE THE VENTILATION GRID TAKING OFF
THE SCREW CAPS.
MITHRA - Modelli: M-L-S-SM-SL
CLEANING AND MAINTENANCE
IF THE CABINET IS VISIBLE ON ALL SIDES, THE REAR GRID MAY BE ROTATED TO AVOID DISPLAYING THE REFRIGERATION SYSTEM. THIS
OPERATION IS NOT RECOMMENDED IF THE CABINET IS PLACED AGAINST A WALL BECAUSE OF BETTER THE VENTILATION.
REVERSAL OF REAR GRILLE
TILT THE GRID SLIGHTLY AND RAISE IT. TURNING
IT BY 180 YOU REVERSE THE VENTILATION FANS
INSTALLING THE SCREWS AGAIN FOR AN AESTHETIC FACTOR IT IS POSSIBLE
TO INVERT THE GRID. HAVING REMOVED THE
SCREW CAPS, UNSCREW THE TWO SCREWS.
THIS OPERATION CAN MAKE LESS EFFICIENT
THE AREATION
IF YOU DON’T OBTAIN THE RIGHT SET-UP, ACT
ON THE WHEEL ON THE REAR LEFT SIDE AND
SCREW COUNTERCLOCKWISE
ACTING ON THE HINGE SIDE WHEEL,
UNSCREWING IT COUNTERCLOCKWISE, THE
DOOR LIFT
PUT THE CABINET WITH THE DOOR IN FRONT
OF YOU
IF THE DOOR CLOSES BADLY AND TOUCHES AT
THE BOTTOM, YOU MUST ACT ON THE WHEEL AT
THE RIGHT SIDE/HINGE SIDE, OR ON THE LEFT
SIDE ON THE REAR.
DX
DX
SX
7.1
7.3
7.2
7.4
