SCAN DSA 5 - Combustible Wall Clearance:; Non-Combustible Wall Clearances:

10
Combustible Wall Clearance:
WARNING: Minimum clearance to combustibles must be observed when installing this stove.
The listed clearances for your DSA 5 are determined in laboratory tests.
If the stove is to be placed at side and back walls of combustible materials the following clearances
must be kept:
Clearances to combustible surfaces*
*The clearances may only by reduced be means
approved by the regulatory authority
+
Non-Combustible Wall Clearances:
The DSA stove is a double-skinned convection stove, which means that the temperatures at the rear
of the stove are reduced. This makes it possible to place your DSA 5 next to non-combustible
materials without any distance needed. However, we recommend that you leave enough space in
order to facilitate the cleaning at the rear of the stove.
USA Canada
Rear wall installation Inch mm.
A – stove to side wall 17
432
B – stove to back wall 3
127
C – flue collar to side wall 29 736
D – flue collar to back wall 9
229
Corner installation
E – stove to adjacent wall 9 279
F – flue collar to adjacent wall 20
508
